Netty框架入门（二）之基于Netty实现简单的Rpc调用

小半 • • 后端开发 • 阅读 305

导读：本篇文章讲解 Netty框架入门（二）之基于Netty实现简单的Rpc调用，希望对大家有帮助，欢迎收藏，转发！站点地址：www.bmabk.com

一、思路原理

Netty框架入门（二）之基于Netty实现简单的Rpc调用

  1.  当启动服务提供者（Netty服务器），将服务注册到zookeeper上，也就是在zk上创建/xiaojie-dubbo/com.xiaojie.api.UserService/providers/xiaojie-dubbo://127.0.0.1:8080方法名称等信息。
  2. 服务发现，从zookeeper节点上获取到服务列表[xiaojie://127.0.0.1:8080…,xiaojie://127.0.0.1:8081….]，然后通过轮询、权重、一致性hash，随机等负载均衡算法获取服务。
  3. 当有服务下线或者宕机之后，通知服务调用者（zk事件通知实现，我没有实现）服务下线或者宕机。
  4. 通过反射，获取实现类的方法，调用之后，消费者通过代理模式，代理出来客户端的类，进行方法的调用，然后通过netty中ChannelInboundHandlerAdapter的channelRead(）将获取的数据写出去。
  5. 利用户Jboss Marshalling解码器MarshallingDecoder、MarshallingEnecoder进行解码。

二、代码

代码结构如下

Netty框架入门（二）之基于Netty实现简单的Rpc调用

 自定义注解代码

package com.xiaojie.dubbo.annotation;

import java.lang.annotation.*;

/**
 * 自定义rpc注解
 */
@Documented
@Inherited
@Target({ElementType.TYPE})
@Retention(RetentionPolicy.RUNTIME)
public @interface RpcAnnotation {
    Class value();
}

服务的注册

package com.xiaojie.dubbo.server.register;

import org.I0Itec.zkclient.ZkClient;

import java.net.URLEncoder;

/**
 * 将服务注册到zk上
 */
public class ServiceRegisterImpl  implements ServiceRegister{
    //定义zk地址
    private String zkServer="127.0.0.1:2181";
    //超时时间
    private Integer timeOut=5000;
    //zkclient
    private ZkClient zkClient;

    public ServiceRegisterImpl() {
        zkClient = new ZkClient(zkServer,timeOut);
    }

    //定义跟节点
    private  String rootNode="/xiaojie-dubbo";
    @Override
    public void register(String serviceName, String servicePath) {
        System.out.println("..............");
        if (!zkClient.exists(rootNode)){
            zkClient.createPersistent(rootNode); //xiaojie-dubbo
        }
        //rootNode+"/"+serviceName
        String serviceNameNode=rootNode+"/"+serviceName;
        if (!zkClient.exists(serviceNameNode)){
            zkClient.createPersistent(serviceNameNode); //xiaojie-dubbo/com.xiaojie.api.UserService
        }
        String providerNode=serviceNameNode+"/"+"providers";
        if (!zkClient.exists(providerNode)){
            zkClient.createPersistent(providerNode);//xiaojie-dubbo/com.xiaojie.api.UserService/providers
        }
        //创建我们服务地址
        String serviceAddresNodePath = providerNode + "/" + URLEncoder.encode(servicePath);
        System.out.println("serviceAddresNodePath:" + serviceAddresNodePath);
        if (zkClient.exists(serviceAddresNodePath)) {
            zkClient.delete(serviceAddresNodePath);
        }
        zkClient.createEphemeral(serviceAddresNodePath);//xiaojie-dubbo/com.xiaojie.api.UserService/providers/getName....
    }
}

服务绑定

package com.xiaojie.dubbo.server.rpc;

import com.xiaojie.dubbo.annotation.RpcAnnotation;
import com.xiaojie.dubbo.server.handler.ServerHandler;
import com.xiaojie.dubbo.server.marshalling.MarshallingCodeCFactory;
import com.xiaojie.dubbo.server.register.ServiceRegister;
import com.xiaojie.dubbo.server.register.ServiceRegisterImpl;
import io.netty.bootstrap.ServerBootstrap;
import io.netty.channel.ChannelFuture;
import io.netty.channel.ChannelInitializer;
import io.netty.channel.nio.NioEventLoopGroup;
import io.netty.channel.socket.SocketChannel;
import io.netty.channel.socket.nio.NioServerSocketChannel;

import java.util.HashMap;
import java.util.Map;

public class NettyServer {
    /**
     * 核心过程是将服务绑定到zk
     * 启动netty服务实现监听
     */

    private ServiceRegister serviceRegister;
    //host
    private String host;
    //端口号
    private Integer port;

    private Map<String,Object> handlerMap=new HashMap<>();
    public NettyServer( String host, Integer port) {
        this.host = host;
        this.port = port;
        serviceRegister = new ServiceRegisterImpl();
    }

    public  void bind(Object obj){
    //获取类上注解
        RpcAnnotation declaredAnnotation = obj.getClass().getDeclaredAnnotation(RpcAnnotation.class);
        if (declaredAnnotation == null) {
            throw  new RuntimeException("declaredAnnotation is null");
        }
        //获取名称，也就是serviceName
        String serviceName = declaredAnnotation.value().getName();
        String serviceAddr="xiaojie://"+host+":"+port;
        serviceRegister.register(serviceName,serviceAddr);
        handlerMap.put(serviceName,obj);
    }

    /**
     * 创建netty服务端,开启监听
     */
    public void initNetty(){
        //创建线程接收请求
        NioEventLoopGroup bossGroup = new NioEventLoopGroup();
        //创建线程处理请求
        NioEventLoopGroup workGroup = new NioEventLoopGroup();
        ServerBootstrap serverBootstrap=new ServerBootstrap();
        serverBootstrap.group(bossGroup,workGroup).channel(NioServerSocketChannel.class)
                .childHandler(new ChannelInitializer<SocketChannel>() {
                    @Override
                    protected void initChannel(SocketChannel socketChannel) throws Exception {
                        socketChannel.pipeline().addLast(MarshallingCodeCFactory.buildMarshallingDecoder());
                        socketChannel.pipeline().addLast(MarshallingCodeCFactory.buildMarshallingEncoder());
                        socketChannel.pipeline().addLast(new ServerHandler(handlerMap));
                    }
                });
        //绑定端口号
        try {
            ChannelFuture channelFuture = serverBootstrap.bind(port).sync();
            //等待服务器监听端口
            channelFuture.channel().closeFuture().sync();
        } catch (InterruptedException e) {
            e.printStackTrace();
        }finally {
            //关闭
            bossGroup.shutdownGracefully();
            workGroup.shutdownGracefully();
        }
    }
    //启动
    public  void start(Object obj){
        bind(obj);
        initNetty();
    }
}

服务发现

package com.xiaojie.dubbo.server.discover;

import org.I0Itec.zkclient.ZkClient;

import java.util.List;

public class ServiceDiscoverImpl  implements  ServiceDiscover{
    //定义zk地址
    private String zkServer="127.0.0.1:2181";
    //超时时间
    private Integer timeOut=5000;
    //zkclient
    private ZkClient zkClient;

    public ServiceDiscoverImpl() {
        zkClient = new ZkClient(zkServer,timeOut);
    }

    //定义跟节点
    private  String rootNode="/xiaojie-dubbo";
    @Override
    public List<String> discoverList(String serviceName) {
        List<String> children = zkClient.getChildren(rootNode + "/" + serviceName + "/" + "providers");
        return children;
    }
}

传送Request的实体类

package com.xiaojie.dubbo.server.req;

import java.io.Serializable;

public class RpcRequest implements Serializable {
    private static final long SerialVersionUID = 1L;
    /**
     * 类的className
     */
    private String className;
    /**
     * 方法名称
     */
    private String methodName;
    /**
     * 参数类型
     */
    Class<?> parameterTypes[];
    /**
     * 参数value
     */
    Object paramsValue[];

    public RpcRequest(String className, String methodName, Class<?>[] parameterTypes, Object[] paramsValue) {
        this.className = className;
        this.methodName = methodName;
        this.parameterTypes = parameterTypes;
        this.paramsValue = paramsValue;
    }

    public String getClassName() {
        return className;
    }

    public String getMethodName() {
        return methodName;
    }

    public Class<?>[] getParameterTypes() {
        return parameterTypes;
    }

    public Object[] getParamsValue() {
        return paramsValue;
    }

    public void setClassName(String className) {
        this.className = className;
    }

    public void setMethodName(String methodName) {
        this.methodName = methodName;
    }

    public void setParameterTypes(Class<?>[] parameterTypes) {
        this.parameterTypes = parameterTypes;
    }

    public void setParamsValue(Object[] paramsValue) {
        this.paramsValue = paramsValue;
    }

    @Override
    public String toString() {
        return className + "," + methodName + "," + parameterTypes + paramsValue;
    }
}

通过反射执行方法

package com.xiaojie.dubbo.server.handler;

import com.xiaojie.dubbo.server.req.RpcRequest;
import io.netty.channel.ChannelHandlerContext;
import io.netty.channel.ChannelInboundHandlerAdapter;

import java.lang.reflect.Method;
import java.util.Map;

public class ServerHandler  extends ChannelInboundHandlerAdapter {
    private Map<String,Object> handlerMap;

    public ServerHandler(Map<String, Object> handlerMap) {
        this.handlerMap = handlerMap;
    }

    @Override
    /**
     * 服务器端监听客户端的消息
     */
    public void channelRead(ChannelHandlerContext ctx, Object msg) throws Exception {
        RpcRequest req=(RpcRequest) msg;
        if (req==null){
            throw  new RuntimeException("req is null");
        }
        //获取serviceName 接口路径
        String serviceName = req.getClassName();
        //实现类
        Object objectImpl = handlerMap.get(serviceName);
        if (objectImpl == null) {
            throw  new RuntimeException("service is not exist");
        }
        //反射获取方法
        Method method = objectImpl.getClass().getMethod(req.getMethodName(), req.getParameterTypes());
        //执行实现类方法
        Object result = method.invoke(objectImpl,req.getParamsValue());
        //返回结果给客户端
        ctx.writeAndFlush(result);
    }
}

客户端通过代理模式执行方法

package com.xiaojie.dubbo.server.proxy;

import com.xiaojie.dubbo.server.discover.ServiceDiscover;
import com.xiaojie.dubbo.server.discover.ServiceDiscoverImpl;
import com.xiaojie.dubbo.server.handler.ClientHandler;
import com.xiaojie.dubbo.server.loadBalance.LoadBalance;
import com.xiaojie.dubbo.server.loadBalance.LoopBalance;
import com.xiaojie.dubbo.server.loadBalance.RandomBalance;
import com.xiaojie.dubbo.server.loadBalance.WeightBalance;
import com.xiaojie.dubbo.server.marshalling.MarshallingCodeCFactory;
import com.xiaojie.dubbo.server.req.RpcRequest;
import io.netty.bootstrap.Bootstrap;
import io.netty.channel.ChannelFuture;
import io.netty.channel.ChannelInitializer;
import io.netty.channel.nio.NioEventLoopGroup;
import io.netty.channel.socket.SocketChannel;
import io.netty.channel.socket.nio.NioSocketChannel;

import java.lang.reflect.InvocationHandler;
import java.lang.reflect.Method;
import java.lang.reflect.Proxy;
import java.net.InetAddress;
import java.net.InetSocketAddress;
import java.net.URLDecoder;
import java.util.List;

public class RpcClientProxy {

    public  static  <T> T create(Class<T> interfaceClass){
        return (T) Proxy.newProxyInstance(interfaceClass.getClassLoader(), new Class[]{interfaceClass}, new InvocationHandler() {
            @Override
            public Object invoke(Object proxy, Method method, Object[] args) throws Throwable {
                //使用代理拼接地址
                ServiceDiscover serviceDiscover=new ServiceDiscoverImpl();
                List<String> strings = serviceDiscover.discoverList(interfaceClass.getName());
                LoadBalance loadBalance=new RandomBalance();
                String servicePath = URLDecoder.decode((String) loadBalance.select(strings));//[xiaojie-dubbo://192.168.1.110:8080,xiaojie-dubbo://192.168.1.110:8081]
                String[] split = servicePath.split(":");
                String host=split[1].replace("//","");
                Integer port= Integer.valueOf(split[2]);
                //封装具体参数
                RpcRequest rpcRequest = new RpcRequest(interfaceClass.getName(), method.getName(), method.getParameterTypes(), args);
                //启动客户端，发送结果
                return  sendMsg(host,port,rpcRequest);
            }
        });
    }

    /**
     * 客户端发送消息
     * @return
     */
    public static Object sendMsg(String host, Integer port, RpcRequest rpcRequest){
        final ClientHandler clientHandler = new ClientHandler();
        NioEventLoopGroup group = new NioEventLoopGroup();
        Bootstrap bootstrap=new Bootstrap();
        bootstrap.group(group).channel(NioSocketChannel.class)
                .remoteAddress( new InetSocketAddress( host,port))
                .handler(new ChannelInitializer<SocketChannel>() {
                    @Override
                    protected void initChannel(SocketChannel socketChannel) throws Exception {
                        socketChannel.pipeline().addLast(MarshallingCodeCFactory.buildMarshallingDecoder());
                        socketChannel.pipeline().addLast(MarshallingCodeCFactory.buildMarshallingEncoder());
                            socketChannel.pipeline().addLast(clientHandler);
                    }
                });
        //发起同步连接
        try {
            ChannelFuture channelFuture = bootstrap.connect().sync();
            //客户端发送
            channelFuture.channel().writeAndFlush(rpcRequest);
            channelFuture.channel().closeFuture().sync();
        } catch (InterruptedException e) {
            e.printStackTrace();
        }finally {
            group.shutdownGracefully();
        }
        return  clientHandler.getResponse();
    }

}

完整代码https://gitee.com/whisperofjune/netty-dubbo-rpc.git

参考：蚂蚁课堂的netty部分
